Electrical Durability:
4000 cycle,
20 cycles per hour
Mechanical Durability:
15000 cycle,
60 cycles per hour
Number of Poles:
3P
Power Loss:
at Rated Operating Conditions per Pole 73 W
Rated Current (In):
2500 A
Rated Impulse Withstand Voltage (Uimp):
8 kV
Rated Insulation Voltage (Ui):
1000 V
Rated Operational Voltage:
690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics):
(220 V AC) 100 kA,
(230 V AC) 100 kA,
(380 V AC) 100 kA,
(400 V AC) 100 kA,
(415 V AC) 100 kA,
(440 V AC) 100 kA,
(500 V AC) 75 kA,
(690 V AC) 60 kA
Rated Short-time Withstand Current Low Voltage (Icw):
for 1 s 40 A
Rated Ultimate Short-Circuit Breaking Capacity (Icu):
(220 V AC) 1.3 kA,
(230 V AC) 1.3 kA,
(380 V AC) 130 kA,
(400 V AC) 130 kA,
(415 V AC) 130 kA,
(440 V AC) 130 kA,
(500 V AC) 100 kA,
(690 V AC) 80 kA
Rated Uninterrupted Current (Iu):
2500 A
Release:
PR232/P-LSI
Release Type:
EL
Short-Circuit Performance Level:
V
Standards:
IEC
Sub-type:
T8
Terminal Connection Type:
Fixed Circuit-Breakers,
Front
