Voltage Options: Single phase: 120/240V Three Phase - 120/208, 120/240, 277/480, 600V
Available Options
Starting aids
Battery charger:✓
Block heater:✓
Battery blanket :✓
Enclosure
Open set :✓
SA enclosure :✓
Fuel tank
No fuel tank :✓
24 hr :✓
48 hr :✓
72 hr :✓
96 hr :✓
Generator End
Anti condensation heater :✓
PMG :✓
Controllers
DSE 7310 control panel :✓
DES 8610 control panel (paralleling) :✓
Remote annunciator :✓
Engine
Engine Specifications: 1.800 r.p.m.
Rated Output: 9,8kW prp ; 10,7kW standby
Manufacturer: YANMAR
Model: 3TNV76GGEH
Engine Type: 4-stroke diesel
Injection Type: Indirect
Aspiration Type: Natural
Number of cylinders and arrangement: 3-L
Bore and Stroke: 76 x 82 mm
Displacement: 1,116 L
Cooling System: Coolant
Lube Oil Specifications: SAE 3 class 10W30 / API grade CD,CF
Compression Ratio: 23,5
Fuel Consumption ESP: 0.82 Gal/h
Fuel Consumption 100% PRP: 0.74 Gal/h
Fuel Consumption 75 % PRP: 0.58 Gal/h
Fuel Consumption 50 % PRP: 0.46 Gal/h
Lube oil consumption with full load: 0,27
Total oil capacity: 3,5 L
Total coolant capacity: 3,7 L
Governor Type: Mechanical
Air Filter Type: Dry
Inner diameter exhaust pipe: 40 mm
Alternator
Generator: STAMFORD
Model: S0L1.H1
Poles: 4
Connection type (standard): Star - Parallel
Mounting type: S-4 7,5"
Insulation: H class
Enclosure (according IEC-34-5): IP23
Exciter system: Self-excited, brushless
Voltage regulator: A.V.R. (Electronic)
Bracket type: Single bearing
Coupling system: Flexible disc
Coating type: Standard (Vacuum impregnation)
Installation
- EXHAUST SYSTEM.
Maximum exhaust temperature: 797 ºF
Exhaust Gas Flow: 92 cfm
Maximum allowed back pressure: 1000 mm H2o
- NECESSARY AMOUNT OF AIR.
Intake air flow: 32 scfm
Cooling Air Flow: 1,468 scfm
Alternator fan air flow: 148 scfm
- STARTING SYSTEM.
Starting power: 1.1 kW
Starting power: 1.48 HP
Recommended battery: 66 Ah
Auxiliary Voltage: 12 Vdc
- FUEL SYSTEM
Fuel Oil Specifications: Diesel
Fuel Tank: 101.71 Gal
Dimensions
- DIMENSIONS.
Length: 67.91 in
Height: 63 in
Width: 29.53 in
Maximum shipping volume: 73.45 ft3
Fuel tank capacity: 101.71 Gal
Autonomy: 174 Hours
Sound pressure level: 63 ± 2,4 dB(A)@7m
